Write A ReviewThese non-reversing contactors are capable of operating electric single direction capstan and windlass motors. Commonly used in conjunction with remote up/down panel, chain counters, wireless hand held remote controls and/or foot switches to control the motor in the required direction.
The casing of the T6215 is waterproof, however installation in a dry area is always recommended.
These heavy-duty solenoids are suitably rated for Quick winch motors and available in either 12V or 24V DC for either permanent magnet or series wound motors.
Note: Single direction solenoids should only be used where single direction motor rotation is necessary.
Features:
Please note: These solenoids will NOT suit the older Quick Hector models, refer to your winch manual to check which replacement part is required, or contact us.
| Model | T6215-12 | T6215-24 |
|---|---|---|
| Voltage | 12V | 24V |
| Max motor power | 2500W | 3500W |
| Max contact voltage | 48Vdc | 48Vdc |
| Interruption capacity | 500A @ 48V | 500A @ 48V |
| Working current | 150A | 150A |
| Weight | 240g | 240g |
| SKU | JPW-P-QFTT621512000A00 |
| Brand | Quick Nautical Equipment |
